DESCRIPTION

• Print methods: Thermal transfer or direct thermal
• Construction: 12-gauge steel frame
• Single 32 bit 133 Mhz RISC processor

More Standard Features

• 16 MB SDRAM; 8 MB non-volatile Flash memory
• Automatic media/ribbon sensing capability
• Improved head test for element out
• Auto calibration
• Clear media side door for ease of supplies monitoring
• 300 unique darkness settings
• RS-232, Parallel ports
• USB 2.0 port
• Internal ZebraNet 10/100 PrintServer
• ZPL or ZPL II Programming Language
• XML enabled printing
• Mirror feature allows user-defined printer configurations to be retrieved from the network
• Create and design customizable printer LCD menus
• Large (240W x 128H pixels), multilingual, backlit, graphical LCD display
• Transmissive and reflective media sensors
• Multi-level Element Energy Equalizer (E³) for superior print quality
• Unicode™ – Compliant
• Intelligent printhead

Printer Specifications

Resolution: 203 dpi (8 dots/mm)
300 dpi (12 dots/mm)
Memory

• 16 MB SDRAM
• 8 MB Flash

Print width: 6.6″ (168mm)
Print length: 150″ (3810 mm) using continuous media
Print speed: Up to 12″ per second (203 dpi)
Media sensors: Reflective, Transmissive

Media Characteristics

Maximum label and liner width: 7.1″ (180mm)
Minimum label and liner width: 2.0″ (51mm)
Maximum label and liner length: 39″ (991mm) non-continuous to 150″ (3810mm) continuous media
Maximum roll diameter: 8″ (203mm)
Core diameter: 3″ (76mm)
Media thickness: .003″ (.076mm) to .012″ (.305mm)
Media types: black mark, continuous, roll-fed, die-cut, fanfold

Ribbon Characteristics

Outside diameter: 3.2″ (81.3mm)
Standard length: 1476′ (450m) or 984′ (300m)
Ratio: 2:1 and 3:1 media roll to ribbon ratios
Ribbon width: 2.0″ (51mm) to 6.7″ (170mm)
Ribbon setup: Ribbon wound ink side out
ID Core: 1.0″ (25.4 mm)

Operating Characteristics

Operating temperature TT: Operating temperature: 40° F (5° C) to 105° F (40° C)
Thermal transfer DT: Operating temperature: 32° F (0° C) to 105° F (40° C)
Direct thermal Storage temperatures: -40° F (-40° C) to 140° F (60° C)
Operating humidity: 20% to 85% non-condensing relative humidity
Storage humidity: 5% to 85% non-condensing relative humidity
Electrical: Universal power supply with power factor connection 90-264 VAC; 48 – 62 Hz
Agency approvals

• BSMI
• cTUVus
• CCC
• CE
• C-Tick
• EN55022 Class B
• EN55024
• EN61000-3-2,3
• FCC Class B
• GOST-R
• ICES-003 Class B
• IEC 60950-1 / EN60950
• KCC
• NOM
• S Mark
• STB
• UkrSEPRO
• VCCI
• ZIK

Physical Characteristics

Width: 13.31″ (338.1mm)
Height: 15.5″” (393.7mm mm)
Depth: 20.38″ (517.5 mm)
Weight: 67 lbs (30.5 kg)

Related Products

Options

• ZebraNet Wireless Plus Print Server
• ZebraNet Internal Wireless Plus (Discontinued)
• Internal IPv6 Print Server
• IBM Twinax interface
• IBM Coax interface
• Rewind with peel
• Cutter
• Bi-fold media door with clear panel
• Media supply spindle for 40 mm cores
• 64MB Flash Memory with ZPL II and XML
• Scalable and international fonts
• Applicator interface
• ZebraDesigner
• ZebraDesigner Pro
• ZebraDesigner for XML
• ZebraNet Bridge
• Enterprise Connector
• ZebraNet b/g Print Server

Communication and Interface Capabilities

• USB 2.0 port (12 Mbits per second)
• RS-232C/422/485 multi-drop (optional adaptor)
• High-speed, bi-directional, IEEE 1284 parallel interface
• ZebraNet Wireless Plus Print Server
• ZebraNet 10/100 Print Server
• IBM Twinax interface
• IBM Coax interface
• Applicator interface
• IPV6 Print Server
• ZebraNet b/g Print Server
